| Specification Table | |||||
| SPECIFICATION | CN | XY1400-S | XY1500-S | ||
| A | B | A | B | ||
| Injection Unit | |||||
| Screw Diameter | mm | 28 | 32 | 28 | 32 |
| Screw L/D Ratio | L/D | 22.8 | 20 | 22.8 | 20 |
| Shot Volume (Theoretical) |
cm³ | 87 | 114 | 87 | 114 |
| Injection Weight | g | 79 | 103 | 79 | 103 |
| Injection Rate | g/s | 85 | 112 | 85 | 112 |
| Injection Pressure | Mpa | 230 | 177 | 230 | 177 |
| Screw Speed | rpm | 200 | 200 | ||
| Clamping Unit | |||||
| Clamping Force | KN | 1400 | 1500 | ||
| Open Stroke | mm | 380 | 380 | ||
| Space Between Tie-Bars |
mm | 420×420 | 460x460 | ||
| Max.Mould Height | mm | 470 | 450 | ||
| Min.Mould Height | mm | 145 | 160 | ||
| Ejector Stroke | mm | 120 | 120 | ||
| Ejectorforce | KN | 38 | 50 | ||
| Others | |||||
| Max.Pump Pressure | Mpa | 16 | 16 | ||
| Pump Motor Power | Kw | 18.5 | 18.5 | ||
| Heating Power | Kw | 15 | 15 | ||
| Machine Dimensions (L×W×H) |
m | 4.6×1.33×1.9 | 4.85×1.55×1.8 | ||
| Oil Tank Cubage | L | 265 | 265 | ||
| Machine Weight(Approximate) |
t | 4.1 | 4.3 | ||
The relation between temperature of the material tube and plastic parameter in the following form is just for reference,auctual temperature will be established according to long term experience accumulated.
| Plastic Name | Specific Gravity | Melting Point | Shrinkage Ratio | Mould Temperature | Barral Temperature | ||||||
| Nozzle | Middle | End | |||||||||
| Min | Man | Min | Man | Min | Man | Min | Man | ||||
| PS | 1.07 | 100 | 0.4 | 10 | 75 | 180 | 260 | 200 | 260 | 160 | 250 |
| HIPS | 1.00 | 100 | 0.4 | 5 | 75 | 220 | 270 | 190 | 260 | 160 | 250 |
| ABS | 1.05 | 110 | 0.6 | 50 | 80 | 190 | 250 | 180 | 240 | 170 | 240 |
| LDPE | 0.92 | 120 | 1.5-5 | 35 | 60 | 230 | 310 | 220 | 300 | 170 | 220 |
| HDPE | 0.95 | 130 | 2.0-5 | 35 | 60 | 230 | 310 | 220 | 300 | 170 | 220 |
| PP | 0.91 | 176 | 1-2.5 | 50 | 80 | 210 | 300 | 180 | 260 | 160 | 240 |
| PVC | 1.45 | 90 | 0.1-0.5 | 10 | 60 | 170 | 220 | 160 | 195 | 150 | 195 |
| PMMA | 1.19 | 100 | 0.5 | 50 | 90 | 180 | 230 | 160 | 240 | 140 | 220 |
| PA6 | 1.13 | 216 | 0.8-1.5 | 50 | 80 | 210 | 230 | 210 | 230 | 200 | 210 |
| PA66 | 1.14 | 265 | 2.25 | 50 | 80 | 250 | 280 | 240 | 280 | 220 | 280 |
| CA | 1.30 | 230 | 0.5 | 40 | 75 | 180 | 200 | 170 | 190 | 150 | 180 |
| PC | 1.20 | 150 | 0.8 | 80 | 99 | 250 | 320 | 260 | 340 | 280 | 350 |
| POM | 1.41 | 175 | 2.0 | 50 | 90 | 190 | 210 | 175 | 220 | 160 | 210 |
| SAN | 1.09 | 115 | 0.2 | 50 | 80 | 250 | 250 | 180 | 230 | 170 | 220 |
